TENGYU Modern Aluminum Sliding Glass Barn Door Hardware Track Kit System on China WDMA

Product Description Sliding Glass Door Hardware accessories High quality Sliding Barn Wooden Door Hardware Features: Moern sliding wood door use for living room,bed room,cabinet,hotelAccommodates doors up to 265 poundsConstructed from carbon steel for long product lifeIncludes all mounting hardware and detailed instructions for a quick and easy installationTested to meet...
$59.00

China Windows and Doors Manufacturers Association

Product Description

Sliding Glass Door Hardware accessories

High quality Sliding Barn Wooden Door Hardware

Features:

Moern sliding wood door use for living room,bed room,cabinet,hotel
Accommodates doors up to 265 pounds
Constructed from carbon steel for long product life
Includes all mounting hardware and detailed instructions for a quick and easy installation
Tested to meet ANSI/BHMA Grade 1 standards
Pass the 100,000 cycles running time and 96 hours salt spray test

PART LIST

One (1) track with mounting screws
Two (2) hangers
Five (5) spacers
Two (2) door stops with cusions
Two (2) Anti-jump blocks
One (1) bottom fin guide
One (1) spanner
Door panel and door knob is available

Product Name
High end stainless steel Furniture Accessories suit for Sliding Door
Material
304 stainless steel
Color
satin
Certificate
ITS SGS ISO
Grade
Grade 1 standards,Tested to meet ANSI/BHMA
Finish
Brushed satin
Max Door Open
1000 mm,for openings wider than 1000mm combine multiple kits with the TYS adaptor
Max Loading Weight
265lbs
Product Weight
14lbs
Wood door thickness
8-12 mm
Rail size
Dia 25mm, Thickness:2mm
Package
1set/white carton 2040*125*70 mm
Products Show

Other Roller Metal Fittings Designs:

Related Products

TY2503

Round tail sliding wooden barn door hardware kits

TY2512

Round tail sliding wooden barn door hardware kits

iNDUSTRIAL DESIGN

Flat sheet sliding barn door hardware.

Price: 1x.x USD/SETS

50KG max loading

Fit for solid wooden door

Salt spray test passed

Lifespan 100,000 cycles

TSQ04-47


TSQB04


TSQ05SN


Our Company
Packing & Delivery

Package

The rail in bubble bag with end protector and each component in proper position in EPE foam.Each set into one carton.

Outer Carton

The carton will be shrinked which will waive the adhesive tapes.The carton can be print or paste company logo.
Carton size:2040x105x80mm

Ply-wood Pallet

Around 84 sets into one plywood pallet,the pallet size:212x81x112cm

Retail Package

Another package for retail,all the parts in EPE form,then into a clear box,so customers can easier to see the products and surface.

Stand Wood Pallet

The stand wood pallet for retail,can put into the shelves directly.

Container & Delivery time.

The loading QTY for 20GP/40GP/40HQ is 1176/2352/2912 sets.
The delivery time is 25-35 days.

Our Certifications
Our Service

OEM and ODM are both available
Sample Available,sample fee will deducted from next official order
Our R&D dept would launch new products each month and willing to developing any items you are interested
We have good quality control managed by our complete QC system (Incoming QC+In-line QC+Final QC)
Independed Art&Design dept,any customed package are available
We will attend to exhibition in North America and Europe every year and we are glad to meet you

FAQ

Q: Are you trading company or manufacturer ?

A: We are a factory with designing, manufacturing, marketing and exporting together,200 employees,10 R&D Engineers in the company.

Q: Can I get some samples?

A: Yes, sample orders welcomed ,the fee will be deducted in the next official order.

Q: What is the payment term?

A: 30% T/T in advance and the balance against the documents.

Q: What's your capacity?

A: Our capacity can be 15,000 sets per month and normally delivery time is 30 days.
