Customized insulated glass sliding window track system design on China WDMA

Customized insulated glass sliding window track system design  Product Introduction ODM Aluminum Profile - Windows & Doors System Series 1st Generation  GR-65 (casement window, awning window, tilt and turn window) GR-65 Series is the first generation products of GEORGIA. It is suitable for residence, hotel, home decorating project etc.The material...
Type :
$130.00

China Windows and Doors Manufacturers Association

Customized insulated glass sliding window track system design

Product Introduction

Customized insulated glass sliding window track system design

ODM Aluminum Profile - Windows & Doors System Series
1st Generation  GR-65 (casement window, awning window, tilt and turn window) GR-65 Series is the first generation products of GEORGIA. It is suitable for residence, hotel, home decorating project etc.
The material is light and thin that have feature of saving energy. It can match many kind of specis glass, maximize the transparecy area of the glass. And it also have best advantage of competitive price which is the most cost-effective product range.
GR-70 (casement door/window, awning window, tilt and turn window)

GR-70 Series is the best seller since it have many kind of specs can used in various scenarios.

1) 1.4mm with thermal break (GR-70a)

2) 2.0mm with thermal break (GR-70b)

3) 2.0mm non-thermal break (GR-70c)

4) 2.3mm non-thermal break (GR-70d)

Customers can get the most suitable materials and prices according to their own needs.

GR-75 (casement door/window, awning window, tilt and turn window)  GR-75 Series similar to GR-70b on specs of aluminum profile. The most of different that it's wind sash flush to frame. The design makes window more integrated. So it is modern style products.
GR-85 (folding door) GR-85 Series made for folding doors. This profile is specially used for folding door. It has a good bearing capacity, can meet kind of glass specs for customer choose. In the course of use, the doors can be stacked on top of each other as much as possible. GR-85 is born for folding doors.
GR-80 & GR-90 (sliding door/window, single/double hung window)  GR-80 Series is sliding type. Generally used in sliding window, single/double hung window. The profile with 1.4mm thickness non-thermal break. It is light and thin that the representative of the concise style. And also have high competitive price.
GR-90 Series can be understoood as the upgrade of GR-80. It same have 1.4mm thickness profile, but we've add thermal break structure. Improved heat insulation and sound insulation performance. And on the inside, we do a design of waterproof bar, then it better used in exterior project.
2nd Generation GR-100 & GR-125 (casement window/door with screen)

GR-100 Series is casement window with screen. The series is low edition of GR-125a. It is 1.6mm profile thickness, but also have thermal break structure. It can match requirements of some customers are keen on thinness. And it's price also more competitive compare for GR-125.

GR-125 Series with screen. It can be used not only for Windows, but also for doors product. The profile series is representative of GEORGIA's second generation products. It's also the best seller, and accept the majority of customers test many years. High quality, High specs, High sales, 3H Series.

GR-115 & GR-120 (sliding door/window) GR-115 & GR-120 can be understood upgrade of GR-80, GR-90. Its also belong with our second generation product, more use in sliding doors. The boths is 2.0mm thickness profile, and all design with waterproof bar inside. The both series sliding door widely used in house, villa, school, hotel, office building etc.                            GR-120 also have type non-thermal break. (GR-120b)
3rd Generation  GR-139 & GR-150 (heavy duty sliding door, pivot door)

GR-139 & GR-150 Series is heavy duty sliding door. It offen used for commercial projects or high specs requirements time. The profiles bottom will equip with 4 pulley fittings for each panel. The accessories can match requirement of laminated insulated tempered glass. We promised quality warranty 10 years.

GR-150 Series can be make flooring spring door (Pivot door).

GR-160 (Heavy duty casement door/window with screen) GR-160 also is heavy duty series. It used in casement window or door, can match screen swing panel design. The profiles can meet the requirement of super size. It is the widest materials in all series profile.

Customized insulated glass sliding window track system design

Product Aluminum sliding window
Size  Customized
Materials



Aluminum profile Series GR-90

Thickness

1.4mm

Structure Thermal break
Finished Powder coated/PVDF/Anodized
Color  White/Grey/Wood grain etc
Glass



Channel

22-40mm

Type Tempered glass/Laminated glass/Insulated glass etc

Thickness

Single: 5, 6, 8, 10, 12
Double: 5+9A+5, 5+12A+5, 6+9A+6, 6+12A+6 etc
Triple: 5+9A+5+9A+5, 6+9A+6+9A+6 etc
Color  Clear, frosted, tinted (Broze, green, blue etc)
Certification 3C, IGCC, CE, AS/NZS 2208
Hardware Brand  China: HOPO
Germany: ROTO, HOPPE, SIEGENIA, GU
Other Information  Packages Foam/Bubble +Plywood

Delivery

30-35 days after confirmed the deposit and drawings
Trade terms EXW, FOB, CIF, DDP/DDU
Related Options

Customized insulated glass sliding window track system design

Customized insulated glass sliding window track system design

Customized insulated glass sliding window track system design

Company Profile

Our workmanship

Customized insulated glass sliding window track system design

Office View

Customized insulated glass sliding window track system design

Factory View

Customized insulated glass sliding window track system design

Shipping & Delivery

Customized insulated glass sliding window track system design

Customized insulated glass sliding window track system design

Buyer Feedback

Customized insulated glass sliding window track system design

Customized insulated glass sliding window track system design

Customized insulated glass sliding window track system design



FAQ

Q: Why choose GEORGIA?

Georgia: We are working on aluminum product 20 years. Already served many customers at oversea. With rich experience of building standard, specification requirement, shipping etc.



Q: What is your main product?

Georgia: Our main products that aluminum windows, doors, skylights and glass sunroom. Its included aluminum profile, glass, hardware, accessories.



Q: How can I know your price?

Georgia: The price based on buyer's requirements, so pls provide below information to help us quote exact price to you.

1) Shop drawing / window schedule to show the window's dimension, quantity, type, and other requirements;

2) Aluminum frame color;

3) Specification of glass: Thickness (Single, double, laminated or others) and color (Clear, tinted, low-e, reflective or others, with Argon, Air or without).



Q: What is the standard size of your windows and doors?

Georgia: Our product is customized made. We will custom size according client require.

1) The window and door custom based on our aluminum profile series.

2) The skylight, sunroom, railing support All-round custom according client project site.



Q: What is your MOQ order?

Georgia: 1 set or 10 sqm.



Q: What is your color available?

Georgia: Our standard color is white, Grey, Wood grain. Other colors can customized. We'll send color chart to you confirm by express.



Q: What is your delivery time?

Georgia: 30 days production time + 30 days shiping time. You can received items around 2 month.



Q: What is your payment terms?

Georgia: 30% - 50% of total amount by T/T as deposit, and balance before delivery.



Q: Will we need to install the glass (Onsite glazing) or do your window come with the glass installed?

Georgia: We'll think about it in terms of the actual situation, ensure the glass will not be damaged during transportation. Generally, we will assemble small size glass. And larger glass is recommended for project site installation.



Q: What is your warranty? (After-sales Service)

Georgia: We promise 10 year quality assurance. If occurence situation of missing accessories when received items, we will free re-sent it by express. And if due to our reason cause glass damaged, Also we'll provided it for free.
