anti mosquito anti rat door window security fly screen stainless steel wire mesh on China WDMA

anti mosquito anti rat door window security fly screen stainless steel wire mesh     Product Description    Stainless steel is heat resistant, acid resistant, corrosion resistant and wear resistant. Because of these characteristics, stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical, etc., mainly used for...
Wire Diameter :
Aperture :
$15.00

China Windows and Doors Manufacturers Association

anti mosquito anti rat door window security fly screen stainless steel wire mesh





Product Description



 Stainless steel is heat resistant, acid resistant, corrosion resistant and wear resistant. Because of these characteristics, stainless steel mesh is widely used in mining, chemical, food, petroleum, pharmaceutical, etc., mainly used for gas, liquid filtration and other media separation.







Specification :
mesh/inch wire diameter/mm aperture/mm mesh/inch wire diameter/mm aperture/mm
2mesh 1.8 10.9 60mesh 0.15 0.273
3mesh 1.6

6.866

70mesh 0.14 0.223

4mesh

1.2 5.15 80mesh 0.12 0.198
5mesh 0.91 4.17 90mesh 0.11 0.172
6mesh 0.81 3.433 100mesh 0.1 0.154
8mesh 0.6 2.575 120mesh 0.08 0.132
10mesh 0.55 1.99 140mesh 0.07 0.111
12mesh 0.5 1.616 150mesh 0.065 0.104
14mesh 0.45 1.362 160mesh 0.065 0.094
16mesh 0.4 1.188 180mesh 0.053 0.088
18mesh 0.35 1.06 200mesh 0.053 0.074
20mesh 0.3 0.97 250mesh 0.04 0.061
26mesh 0.28 0.696 300mesh 0.035 0.049
30mesh 0.25 0.596 325mesh 0.03 0.048
40mesh 0.21 0.425 350mesh 0.03 0.042
50mesh 0.19 0.318 400mesh 0.025 0.0385



 Stainless steel mesh is classified according to the variety: 1. Stainless steel plain mesh. 2, stainless steel twill net. 3, stainless steel bamboo pattern net. 4, five comprehensive stainless steel mesh. 5, stainless steel punching net. 6, stainless steel ginning net. 7, stainless steel chain link flower net. 8, stainless steel mesh. 9, stainless steel welded wire mesh. 10, stainless steel hexagonal net. 11, stainless steel mat network. 12, stainless steel barbecue net. 13, stainless steel ore screen. 14, stainless steel tortoise shell net.





 Stainless steel mesh
Materials: stainless steel woven mesh, copper mesh, mat mesh, stainless steel sintered mesh, stainless steel square mesh, metal mesh, steel mesh, punched mesh and other metal mesh.
Stainless steel edging mesh









 Stainless steel edging mesh
Edge material: stainless steel plate.
Product shape: rectangular, square, round, oval, ring, rectangle, hat, waist, profile
Stainless steel spot welded mesh
Materials: stainless steel woven mesh, copper mesh, mat mesh, stainless steel sintered mesh, stainless steel square mesh, metal mesh, steel mesh, punched mesh and other metal mesh.











 Product structure: single layer, double layer, three layers, four layers, five layers, multiple layers.
Processing size: 6 mm to 650 mm.
Product classification: single-layer filter mesh, multi-layer spot welding filter mesh, edging filter mesh, combined filter mesh.















Packing pictures











Produce process









Canton Fair









Factory information





Suicheng Metal Product Co.LTDestablished in 1988.

We are a large scale enterprise that integrates the R&D,

Production and scale of wire mesh.

By research the wire mesh industry  extensively for years

And through our professional knowledge ,we received

 excellent  reputation both home and abroad.

 We have two factories & an export office in Guangzhou,

welcome to visit us at any time!

Factory 1: Bei Xin Ying Industrial Zone, AnpingCounty,

Hebei Province, China.
Factory 2: No.117-7, NanzhouRoad, Lijiao Village, Haizhu,

 Guangzhou, Guangdong, China
Showroom: Room 321, ZhongzhiCommercial Building No.911,

Haizhu District,Guangzhou City, China
