Aluminum sliding glass patio doors with big size tempered glass for commercial use on China WDMA

                        Aluminum sliding glass patio doors with big size tempered glass for commercial use             MSKING ALUMINUM         TABLE OF CHEMICAL COMPOSITION OF ALUMINUM ALLOY Alloy Si Mg Fe  Cu Mn Zn...
color :
Light Grey

China Windows and Doors Manufacturers Association

                        Aluminum sliding glass patio doors with big size tempered glass for commercial use

MSKING ALUMINUM

Aluminum sliding glass patio doors with big size tempered glass for commercial use

Aluminum sliding glass patio doors with big size tempered glass for commercial use







TABLE OF CHEMICAL COMPOSITION OF ALUMINUM ALLOY
Alloy Si Mg Fe  Cu Mn Zn Cr Ti Impurity     AL
6063 0.2-0.6 0.45-0.9 <0.35 <0.1 <0.1 <0.1 <0.1 <0.1 <0.15 Rest
6061 0.4-0.8 0.8-1.2 <0.7 0.15-0.4 <0.15 <0.25 0.04-0.35 <0.25 <0.15 Rest
6060 0.3-0.6 0.35-0.6 0.1-0.3 ≤0.1 <0.1 ≤0.15 ≤0.15 0.106 <0.15 Rest
Structure Aluminum Alloy                                                                                Tolerance: +/-0.1 , and +/-0.15





                                                    MSKING Aluminum Sliding Gray door
Aluminum profile/frame  6063 T5  aluminum alloy / 1.4--3.0 mm thickness
Tempered glass  Single glass  6/10/12mm Standard :  Configurations available: a. Low-E glass                    b. Argon gas gap                c. Tinted glass                      d. Frosted glass                    e. Laminated glass              f. Color back glass              g. Bar design              h. Blinds inserted
  Double glass standard:6mm+12air+6mm


Triple glass



Standard:5mm+6air+5mm+6mm+5mm
Surface finish Powder Coatings  Standard : white , black , grey,yellow,dark grey,dark yellow Cream yellow,Silver gray,Beige all the powder coating color can be produced
  Anodized Slivery ,champagne,gray,dark gray,brown ,dark brown ,black and so on .all colors in the world can be produced.
  Fluorine carbon coating Corrosion resistant, used for the house near the sea
  Wood grain color All wood color can be produced
  Polishing color

All polishing color can be produced




Hardware  Standard:Chinese KINLONG  ,Germany brand
Fly Screen  Fiberglass fly net ,Stainless steel mesh ,  Bi fold screen
MSKING Advantages

No.1 Advantage: Produce Aluminium Ingot and aluminum billet ourself
No.2 Advantage: Already have more than 40 countries and areas moulds and familiar with the quality demands .
No.3 Advantage: Extruders from 800Ton~6400 Ton covered most dimensions of the Industry profiles
No.4 Advantage: CNC machining workds & Colorings.
No.5 Advantage: STRONG R&D: Help customers finalize the design, strong tool design ability,excellent pressing and surface treament technology.
No.6 Advantage: Strict quality management: ISO Administration system.
No.7 Advantage: High capacity of manufaturing and wide range of products.
No.8 Advantage: Be able to provide secondary fabricating.
No.9 Advantage: Be able to provide one-stop supply solution

No.10Advantage: Provide aluminum window and door for top 10 estate company in China



Aluminum sliding glass patio doors with big size tempered glass for commercial use Aluminum sliding glass patio doors with big size tempered glass for commercial use Aluminum sliding glass patio doors with big size tempered glass for commercial use Aluminum sliding glass patio doors with big size tempered glass for commercial use Aluminum sliding glass patio doors with big size tempered glass for commercial use





Aluminum sliding glass patio doors with big size tempered glass for commercial use





Product Process

Aluminum sliding glass patio doors with big size tempered glass for commercial use   Aluminum sliding glass patio doors with big size tempered glass for commercial use

About US

Quality Control

Aluminum sliding glass patio doors with big size tempered glass for commercial use

Packing

Aluminum sliding glass patio doors with big size tempered glass for commercial use

Packaging&Shipping
Small goods will be packed on steel pallet or plywood box. Profile surface will have plastic film

cover, aluminum window and door corner would be protected by paper corner gloves. Packing

belt will hold goods fasten on the pallet. Stretch wrap will be used for cover whole steel pallet.

Standard Export packing and Loading container
 Air bubble film inside+wooden crate outside.
Other packing methods as customer's requirement.

Packing detail:
20ft: 200pcs for window with normal size(1.2mx1.2m)
        90pcs for Doors with normal size(1.8mx2.2m)
40ft: 420pcs for window with normal size(1.2mx1.2m)
        200pcs for Doors with normal size(1.8mx2.2m)
40HQ:530pcs for window with normal size(1.2mx1.2m)
           250pcs for Doors with normal size(1.8mx2.2m)

Pls kindly note:
We are a factory not a foreign trade company,we can offer high quality products, competitive price fast delivery time and outstanding after sale service. we welcome every foreign buyer to visit our factory to know more about us and products. If you are interested in any of our products or would like to discuss a trail order, pls feel free to contact us for more informations and pictures. We will getback to you ASAP.


FAQ:
1. Can you tell me what kind of hardware you can supply?
It's a very good problem,actually the hardwares are very very important for window and door,more than the aluminum profile.It decides the life of the door&window.So we are doing our best to  offer the best to our customers.Most of our hardware is Gemany's famous brand,such as:G-U,SIEGENIA,HOPO,ROTO and SOBINCO etc.The left of them are China's top brand,like CHUNGand KINLONG.

2. What about your package?
We use the standard exporting package:bubble bag+wooden frame or wooden box,we have been exporting many products to overseas,and there's no any clients' complain about our package,so don't worry about the package.

3. What's your price ?
The price is based on your requirement,so please give us information below,favorable price will be given to you asap.
A :Frame profile: Aluminum or pvc
B: Color of the profile: White,Gray,Brown and other wood grain color.(color can be customized)
C.Product size: Drawing can be supplied,that will be better.
D.Type of glass:
1) Thickness: 5mm,6mm,9mm,12mm,can be customized.
2) Layer :single,double or triple
3) Color :clear,tinted or reflective,tempered,low-e or others

4. What's your delivery time ?
About 15-25 days after receiving 30% deposit.

5. How to guarantee your quality ?
We supply you ten years guarantee for the profile frame,glass and the hardwares.If you have any questions,please don't hesitate to contact our seller,we will try our best to solve your problems.







The following is main advantage of MSKING aluminum :



NO.1 Advantage:Produce Aluminum Ingot ourself.So can strictly control the quality and provide best price all the time.

No.2. Advantage: Already have more than 40 countries and areas moulds and familiar with the quality demands

No.3.Advantage:  Extruders from 800Ton~6400 Ton covered most dimensions of the Industry profiles.
No.4. Advantage: CNC machining works & Colorings.
No 5..Advantage  25 year aluminum profile manufacturer Exported over 40 countries.


No.6.Advantage Have independent developed Quality Control and Order Tracking application (customer can

download it and follow their order anytime and anywhere ,also can talk with factory on the App if have any question)



No.7.Advantage Self-owned doors and Windows factory, can produce 5 million square meters of doors and Windows, curtain wall, almost Asia's largest doors and Windows factory.Can produce all kinds of pull push doors and Windows, flat open doors and Windows, hanging rail doors and so on.





MSKING can provide both aluminum profile and aluminum window and doors which have produced over 25 years with many ready moulds available !
